Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)

Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 78

An illustration from Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types, 1908, leaf 78 — best show thepositions at given points of the eccentric travel. Fig. 65 represents the inlet (steam) valve and mechanism asseml>led.The scale is for a size these makers build for cylinders under 16 in. indiameter, or their size A valve. It shows the valve lapped at the innerend of its travel,… … FIG. 66. the pusher crank at the top of its movement, D D is, the pusher-crankcenter at the lower end of its travel, E E is the center line of the pusher-crank shaft, F F is the line of travel of the pusher-plate edge, G G is theline of travel of the pusher-crank pin, a is the pusher, h is the…

Steam-engines

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
