Mechanical movements, powers, devices and appliances; (1903)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 356
I443&. ^lODERN COT-TON GIN.— D, nest of saws. E, saw grate betweeneach saw to holdback the seed. A, feeder trough andhopper. J, cylinder brush strip-ping the cotton fibrefrom the saw. F, adjusting lever. K, sliding mote board. MIIvI/ AND FACTORY APPLIANCES. 347 … 1443c. SPOOL WIND-ING MACHINE.—Aworm screw B and geardrives a set of cams R ona cross shaft and oscillatesa lever and thread guide toand fro. The spool spindledriven by friction gear fromthe shaft B.
Mechanical movements
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
