Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 62

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 62
—/^ … Fig. 18. Take-Up and Parts. bottom of the frame. The spreader bow is supported and rotatedby the vertical shaft. The weight of the take-up is supported bya hardened rounded steel collar (not shown in the cut) seated in ahardened steel cup, 5. This is sufficiently free to allow the take-up to move…

Textile fabrics · Textile industry
