in order to show the aforesaid divisions or teeth, which aremarked in the figure D 1 to 8. There is a semicircular groove formed around the circumference of the aforesaid rim, above the bottoms of its teeth, to receive the clip-band ef. The clip-band «/is formed of a band of round iron oiwire of a… … rod e. The yoke/ is placed in a horizontal position, and presents towards the table D a concave siJ.%which is fitted to the groove in the rim of said table. Said yoke/has a vertical shot formed throughit, the longitudinal centre of which is in continuation of a right lane extending horizontally…
