An illustration from Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1907, leaf 132
mechanism as follows: (SeeFig. 39.) On the left housing plate Z is fixed the bracket M, 117 104 KNITTING in which is joiirnaled the shaft. On the inner end of the shaft is thechain drive lever M^, with a stud roller M^ and on the outer end ofthe shaft is the pawl lever M\ carrying pawls M and M.… … FiK- 47. Top Side of Cap Plate. to which is fixed the sprocket wheel M that carries the pattern chainM. Next to the chain ratchet is the cam wheel M, on the periph-ery of which rests the chain lever M^ which is pivoted in the topof the chain bracket M. To the upper end of this bracket is con-nected…
