d for the reception of the needles; the parts 3 and 4 being soshaped and attached as to leave a circular space in which is placedthe segmental racking guides C. The Racking Mechanism. (Fig. 96.) The racking guides C have 172 KNITTING 157 fastened to the under side the studs c, which are extended… … <— iiSrn r^- STj|U %^J CSi T i^ ^ lever having a cam roller entering one of two grooves in the peripheryof the cam hub c^ fastened to shaft d, having loosely mounted uponit a worm o;ear having its sleeve inserted in a bearing made in the 173 158 KNIITING extension A^ the gear being engaged and…
