Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)

Chicago : American school of correspondence · leaf 284

An illustration from Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1907, leaf 284
and extending 255 238 KNITTING over both ratchets and chain-pulley, and is provided with an arm 47,having a pin 48, which projects into the path of movement of the chain-lugs. A spring 49 is coiled about the pin 46, and tends to hold thearm and shield in position; but when a chain lug raises the… … Fig. 149. during the knitting of one stocking, the length o^ the article and itsshape being controlled by the length of the chain employed and thespacing and number of lugs carried by the chain. The knitting opera-tion itself continues uninterruptedly without regard to the rotation ofshaft and…

Textile industry · Textile fabrics
