f fullpressure shown in Fig. 62. Referring again to Fig. 62, the operation of the parts may bedescribed in detail as follows. The power arm m is pivotally con-nected to the screw-threaded connecting link ?^, which, passingthrough the sleeve on top of the rear upright D, is held in place bythe… … Fig. 58. Brash Belting. snuiU handwlieel <j. By turning this handwheel when the pressureis let olf, the screw link is taken up or let back, thus shortening orlengthening the connections. Hence the amount of pressure ap-plied by turning the shaft h over into its locked or pressing posi-tion, is…
