Davis's manual of magnetism : including galvanism, magnetism, electro-magnetism, electro-dynamics, magneto-electricity, and thermo-electricity (1854)

Davis, Daniel · Boston : Palmer and Hall · leaf 62

An illustration from Davis's manual of magnetism : including galvanism, magnetism, electro-magnetism, electro-dynamics, magneto-electricity, and thermo-electricity, 1854, leaf 62 — GA I. VANO—DECOMPOSITION. 45 … 30 represents a tumbler divided vertically; with theedges ground together, so as to form a tight joint.Fig. 30. when they include between them a diaphragm of unsized paper.They are held together by ringsof India rubber. A little screw-cup is clamped to the side ofeach of these apartments, fromwhich…

Magnetism · Electricity · Electromagnetic Phenomena

Internet Archive · Medical Heritage Library · Public Domain Mark 1.0. Free to use for anything.
