Dental and oral radiography : a text book for students and practitioners of dentistry (1916)
McCoy, James David · St. Louis : Mosby · leaf 60
Fig. 19.Medium-sized high frequency coil. then carried to a condenser. As the currentleaves the condenser it is oscillating at a greatrate of frequency and passes into the primary of X-RAY MACHINES 57 … Fig. 20.Large type high frequency coil. 58 DENTAL AND ORAL RADIOGRAPHY the Tesla or second coil where it induces a cur-rent in the s lary of this coil From the ter-minals of the last secondary, it is carried to thex-ray tube. The principles involved in this type apparatus are shown in Fig. 17. Like…
Radiography, Dental · X-rays · Teeth · Mouth
