Descriptive geometry for students in engineering science and architecture; a carefully graded course of instruction (1915)
Armstrong, Henry F. (Henry Fry), 1868- · New York, J. Wiley & sons, inc.; [etc., etc.] · leaf 81
Fig. 73. EXERCISE XXX … 1. Find the projection of a 2 cube whentwo of the axes of projection are inclined at 25°and 40° respectively to the projection plane. 2. Find the inclination to the projectionplane of the third axis in i. 3. Find by axometric projection a skeletoncube 3I outside, 2\ inside, measurement. Oneaxis is…
Geometry, Descriptive
