The design and construction of oil engines; (1900)
Goldingham, Arthur Hugh. [from old catalog] · New York, Spon & Chamberlain; [etc., etc.] · leaf 180
Diagram from Crossley Engine: Revolutions per minute,180; M. E. P., 50 lbs.; compression pressure, 50 lbs.;maximum pressure, 180 lbs. suction period. The oil then returns through the over-flow-pipe to the tank. 164 OIL ENGINES. The centrifugal governor is actuated by separategearing and horizontal… … shaft, and the governor regulates the speed of theengine by acting on the hit-and-miss system, and con- VARIOUS ENGINES DESCRIBED. 165 trols the vapor inlet-valve to the cylinder. Thus, ifthe required speed of the engine is exceeded, thevapor-valve is not opened, and accordingly only air isdrawn…
Internal combustion engines
