Handbook for the use of electricians in the operation and care of electrical machinery and apparatus of the U.S. seacoast defenses (1902)
United States. War Dept, Anderson, George Lucius, 1849-1934 · Washington, Govt. Print. Off. · leaf 41
26a. Fourth stroke.—Exhaust of the products of combustion from the cylinder intothe exhaust chamber and pipe occiirs during the next inward stroke, or finalcycle. During the first outstroke the thin stream of oil is instantly vaporized onstriking the heated interior surface of the vaporizer, and… … THE HORNSBY-AKROYD OIL iiJNGINE. 31 air heated en route by the hot exhaust chamber, is drawn into the cylinder.Mixture and compression follow on the following instroke, at the end of whichignition is caused by the heating effects of compression, friction, and vaporizerscombined. The impulse is…
