Steam engines, prepared in the Extension division of the University of Wisconsin (1919)
Shealy, Edward Marvin · New York, McGraw-Hill · leaf 20
ith a24 in. stroke) the area of its piston is .7854 X 202 = 314.16 sq. in.and the volume displaced during a single stroke is314.16 X 24 = 7539.84 cu. in. 7539.84 . _. „^or —yj2Q~ ^ 4.305 cu. ft. The clearance volume of this engine is 12 per cent, of 4.305 or.12 X 4.305 = .5166 cu. ft. PRINCIPLES OF… … cyhnder is shown cut away in order to illustrate its interiorconstruction. In Fig. 2, 1 is the foundation of the engine; 2 is the frame; / 6 STEAM ENGINES 3 is the cylinder; 4 is the head end cyHnder head; 5 is the crankend cyHnder head; 6 is the piston; 30 is the piston rod; 8 is thecrosshead; 9…
