k-shaft. The oil-tank is placed abovethe cylinder, and fuel is supplied to the engine partlyby gravitation—the quantity injected, however, into the VARIOUS ENGINES DESCRIBED. 171 cylinder being regulated by small oil-supply pump. Thegovernor is of the inertia type, and acts directly on thepump on… … Fig. 75. missed, and no explosion follows. The governor itselfis actuated from the crank-shaft by eccentric and bellcrank direct. The oil is vaporized in a hot chamberplaced at the back of the cylinder, which is heated for afew minutes in starting by independent lamp; after-ward the heat created by…
