The design and construction of oil engines; (1900)
Goldingham, Arthur Hugh. [from old catalog] · New York, Spon & Chamberlain; [etc., etc.] · leaf 47
s designs incross-section, but that chiefly used is made of soft steeland circular, with marine type brasses at crank-pin endand similar bearings at the piston or small end. Bysome makers the latter bearing is made with adjust-able wedge and screw, the end of the connecting-rod o\ DESIGN [NG OIL… … Fig. 12. The connecting-rod of a single-acting engine has,chiefly, compression strains to withstand; both theouter end bearings have little or no strain on them,except that due to momentum of the reciprocatingparts. The connecting-rod should be from two to 32 OIL ENGINES. three strokes in length.…
Internal combustion engines
