The design and construction of oil engines; (1900)
Goldingham, Arthur Hugh. [from old catalog] · New York, Spon & Chamberlain; [etc., etc.] · leaf 64
1 m Fig. 26. vapor and air is accordingly regulated, and the meaneffective pressure as required is suitably reduced. 48 OIL ENGINES. The indicator diagram illustrates the variation ofthe M. E. P. in the cylinder, as shown in Fig. 25, eachexpansion line registering a different pressure. Noexplosion… … Fig. 27. quently the running of the engine is even and regu-lar. The hit-and-miss type of governor is shown in Fig.26. This device is made in many different forms, themode of working being similar in them all—namely, ON DESIGNING OIL ENGINES. 49 the inertia of a weight controlled by the spring-.…
Internal combustion engines
