ric line, but inclines slightly toward theright hand at top. The diagram also shows the open-ing of the exhaust-valve at the proper time—namely,at 85 per cent, of the stroke. The compression linerepresents the proper pressure, and the air-inlet andexhaust lines indicate correct proportioned valves… … Fig. 39.
