Creighton, William Henry Paul, 1859- · New York, J. Wiley & sons; [etc., etc.] · leaf 340
in Fig. 163. Perpendicular to it, at any givenpoint, erect a line, called the zero line, whose assumed length willrepresent the volume of the low-pressure cylinder plus the clear-ance. Lay off tins clearance. Divide the remainder into anynumber of parts and divide the atmospheric line of the… … Standard Engine Tests Fig. 164. scale of pressures) the pressures as determined by the length of thecorresponding ordinates in the single card. To the same scale of volumes lay off the volume of the high-pressure cylinder and its clearance from the clearance line or lineof zero volume. As before,…
Steam-engines · Heat-engines
