Goldingham, Arthur Hugh. [from old catalog] · New York, Spon & Chamberlain; [etc., etc.] · leaf 106
igs. 76, 98, no). The frameshould be proportioned not only to prevent vibrationand to withstand the strains consequent on the impulsein the cylinder, but should also be ribbed and of amplesectional strength to overcome the vibration known aspanting. Valve Mechanisms.—With the Beau de Rochasor… … Fig. 22. to be well adapted for this work. The power necessaryto operate the valves is, in this case, transmitted fromthe crank-shaft by the worm or skew gearing throughthe cam-shaft, with separate cams opening the air andexhaust valves by the operating levers, as shown inFig. 23. Where…
Internal combustion engines
