Goldingham, Arthur Hugh. [from old catalog] · New York, Spon & Chamberlain; [etc., etc.] · leaf 108
Fig. 23a. Governing Devices.—The governing devices forcontrolling the speed of oil engines are of two kinds:first, that designed to develop centrifugal force, which … ON DESIGNING OIL ENGINES. 45 is balanced either by suitable controlling spring or deadweight, as shown in Fig. 24, and, secondly, the inertiaor pendulum type of governor. The accompanying illustrations also show the meth-od of by-passing the oil where the air supplyis constant at all loads. The…
Internal combustion engines
