Goldingham, Arthur Hugh. [from old catalog] · New York, Spon & Chamberlain; [etc., etc.] · leaf 197
d dynamo is usuallyflexible to allow of dynamo bearings and the engine-shaft bearings remaining in alignment when they be-come worn. In direct-connected plants the loss due tothe belt transmission is avoided, and a saving is thuseffected; but, on the other hand, the first cost of thedynamo is very… … OIL ENGINES DRIVING DYNAMOS II9 twin cylinder horizontal type coupled direct to thegenerator. The illustration shows the engines placedeach side of the generator with two flywheels and con-nected by coupling forged on the shaft. An arrange-ment preferred is the two engines placed side by sidewith…
Internal combustion engines
