Practical mechanical drawing and machine design self taught .. (1907)
Westinghouse, Charles. [from old catalog] · Chicago, F. J. Drake & co. · leaf 92
cast on the stuffing-box. Surrounding the rod onthe top of the gland there is a recess R for holdingthe lubricant. The object of the gland and stuffing-box is toallow the piston rod to move backwards and for-wards freely without any leakage of steam. Example 14. Gland and Stuffing-box for a… … o bo •l-l or steam under high pressure. The plug in thisexample is hollow, and is prevented from comingout by a cover which is secured to the casing by
Mechanical drawing · Machine design
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
