Fig. 77b. VARIOUS ENGINES DESCRIBED. 187 The vertical type Hornsby-Akroyd engine, whichwas previously built, is also shown here in sec-tion (Figs. 78 and 79). The cam-shaft is operated … 188 OIL ENGINES. by a gearing from the crank-shaft in the regular way,the valves being operated by levers and rods. As willbe seen from the illustration, the cylinders are builtseparately, being water-jacketed and mounted on a
