taken in the plane of thedotted line ABC, in fig. 44 and the latter an end elevation(partly in section) of the same. An exterior induction ringor armature of soft iron is securely bolted to the frame of themachine, and is wound with insulated copper wire in eight sec-tions, each of which consists… … 88 IllK KLKlTHU LKillT. Upon each iiliemato one of the eight sections. The inducingmagnet T revolves wiiliin the induction ring, and consists ofeight soft iron cores, K K, etc., projecting radially from a centralhul), II, which is lixed upon a horizontal axis, F, revolving inbearings, and…
