Goldingham, Arthur Hugh. [from old catalog] · New York, Spon & Chamberlain; [etc., etc.] · leaf 51
Fig. 7- A—Air pump connection, a—Air passage to spray-maker. 0—Oil tank connection. uo—Oil passage tospraymaker. B—Supplementary air valve. ber, as shown in Fig. 6a. On the outward or suctionstroke of the piston the mixture of oil vapor and airalready formed and heated in the vaporizer is drawninto…
Internal combustion engines
