Fig-. 42. Setting- a sliding Tee-bevel to an ang-le of 45°. A SCRAP-BASKET 53 … thus: With the scratch awl or asharp nail draw a center line (di-ameter) thru a piece of tin2 X 2^. On this center line layoff four }i spaces. With thescratch awl and sliding Tee-bevelset at 45°, draw oblique linesboth ways from the center line asshown in Fig. 43. With the snips(or a pair of strong…
Woodwork
