omposed of a number of threads or wires threaded between lathsor harness shafts. Each wire or thread has a loop in the middle,or, instead, an eye, called a mail or heddle eye, is threaded uponit, through which the warp thread passes. There are twoheddles shown at H H, one of which receives every… … Fig. 3. DESIGN TEXTS. The arrang-ement of the warp threads, and the various partsof the loom which operate them, may be best understood byreferring- to Fig. 3 on pag-e 7, which is a diagram showing- eachwarp thread separately. In Fig. 3 the harness shafts are shown connected and bal-anced by cords…
