, are providedfor measuring the magnetic azimuth of any ob-ject. Compass, Boxing the ■ —Naming, consecutively, all the different points orrhumbs of the compass from any one of them.(See Compass, Points of.) Compass-Card.—(See Card, Compass) Compass, Inclination -A magnetic needle moving freely in a… … Fig. 162 Inclination Compass. edges so as to be free to move only in the verticalplane of the graduated vertical circle C C. Thiscircle is movable over the horizontal graduatedcircle H II. In order to determine the true angleof dip, the vertical plane in which the needle isfree to move must be…
