ectedin series. Since in a series-wound dynamo the armaturecoils, the field and the external series circuit are inseries, any increase in the resistance of the externalcircuit will decrease the electromotive force fromthe decrease in the magnetizing currents. A de-crease in the resistance of the… … Fig. 355- Series Dynamo. The dynamo shown in Fig. 355 is series con-nected. The armature is ring-shaped. Thearmature core consists of a ring made of sort ironwire. The field is bi-polar, and is obtained bythe use of four magnet coils and two consequentpoles. Machine, Dynamo-Electric, Shunt…
