A dictionary of electrical words, terms and phrases (1896)
Houston, Edwin J. (Edwin James), 1847-1914 · New York, The W.J. Johnston company · leaf 112
Fig. 132. Series Circuit. being connected by conductors with the externalcircuit. The connection of three Leclanche cells inseries is clearly shown in Fig. 133. The carbons, … Fig, 133. Voltaic Cells Connected in Series. C, C, of the first and second cells are connected tothe zincs, Zn, Zn, of the second and third cells,thus leaving the zinc, Zn, of the first cell, and thecarbon, C, of the third cell, as the terminals ofthe battery. The direction of the current isshown…
Electricity · Electrical engineering
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
