Principles and practice of electrical engineering (1914)
Gray, Alexander, 1882-1921 · New York [etc.] McGraw-Hill Book Company, inc. · leaf 291
h increase of load; this drop however is small, beingless than 2 per cent, for a 5 kv.a. transformer at 100 per cent,power factor, while for leading currents in the secondary circuitthe secondary voltage may rise with increase of load just as inthe case of the alternator, see page 245; the student… … A B Fig. 310.—Leakage flux of transformers. Xi and X2 are kept small by constructing the transformer sothat 4>u and <£2z are small. Diagram A, Fig. 310, shows a trans-former with a primary and a secondary coil on each leg and showsalso the leakage fluxes. It may be seen from this diagram…
Electrical engineering
