the apex of tlieroof, the illusion disappears, and the expédient, which I hâve em-ployed as a precautionary measure, to prevent the sagging of the tie-beam, satisfies the doubt of the eye. This illusion then has warnedme of the real weak point in my truss ; it has prompted me to findout the only… … If, in Eig. 50, I construct a perfectly vertical pier, and if to thefîank of this pier at C I communicate the thrust of a vault, the arcC D will cause the pier to seem to bend inward at the point ofthrust C, especially if, at A, I hâve another arc which opérâtes to OCULAR IXSTIXCT IX DESIGX. 295…
