iately superposed. It need not be added that the panelsmay be moulded into sunk compartments, so as to form aninterior decoration. The centering for a dome thus covered in by means ofmoulded panels will not need planking, as each panel presents asolid surface. All that is needed therefore is thu-ty… … Fio. 15. -Method of centering for Vaulted Dome. poses, or be exchanged when the work is completed. If therefore,fig. 15, we fix up a circle of T-iron or even cast-iron at A, andanother circle of angle-iron at B; if as an extra pi-ecaution we tiethis lower circle with fifteen tie-rods c, bolted to a…
