thiskind necessarily demand a certain thoroughness of execution.Thus the walls must be well founded and built; their superincum-bent weight shoidd be sufficient to insure great firmness in thebuilding from i to k. The springers of the arches should beformed above the abutment of the column c, in… … S»Jii^i.iUi>iLir Fio. 3.—Novel method of resisting the thrust of Vaulting. c, and the surface n the capital of the column d. Two bars ofdouble T-iron, or plate-iron with angle-pieces riveted on, willfasten, the outer ones at o, and the inner ones into grooves pro-jecting from the sides of the…
