The practical draughtsman's book of industrial design, and machinist's and engineer's drawing companion: forming a complete course of mechanical, engineering, and architectural drawing. (1857)
Armengaud, aîné (Jacques-Eugène), 1810-1891, Armengaud, Charles A., 1813-1893, Amouroux, Jules, Johnson, William, 1823-1864 · New York : Stringer & Townsend · leaf 186
ew, corresponding to the pitchof the guide-screw; l, grooved shaft, in connection with the dif- BOOK OF INDUSTRIAL DESIGN. or barrelling motion, which is attached to the verticalslide, and consists of a segmental screw-wheel, embracing a mo-tion of about 60°, gearing with a tangent-screw on the… … Fig. 2, bearings of the screw, which slide in dovetails, and consequentlythe vertical slide, being thus affected by the eccentricity of thecrank-pin. The shafts, a, h, and i, and screws, g and k, are con-nected by a system of wheels, the arrangement of which is clearlyshown in the end view, fig. 2;…
Mechanical drawing
