Draw frames and fly frames : being a practical treatise on the above machines (1898)
Thornley, T. (Thomas) · Manchester : A. Heywood · leaf 38
nder. The highspeed at which the front roller of a draw-frame is run,combined with its strength and the lightness of the variousparts of the frame, enables the power to be distributedvery effectively from this roller. The driving of the other three pairs of drawing rollersmay first be traced. It… … fit 28 on the back roller. These are the wheels concerned in thetotal draft along with the diameters of the back and frontrollers. A 34 on back roller drives a 16 on the second rollerfrom the front by means of a 56 carrier wheel. A 22 onback roller, by means of another 56 carrier, drives an 18…
Textile machinery
