Metal-work; a handbook for teachers and students (1914)
Adam, Hugh M. [from old catalog], Evans, James Humphrey, [from old catalog] joint author · New York, Longmans, Green and co.; London, E. Arnold · leaf 332
inebetween the breast-piece P and the end AB of the frame, thesection to be taken at the centre line CD. Do not draw thepiece marked P. Arrange for the pin on the wheel Wj to fitin either of the holes H^ or Hg, and to gear with portions of thewheel W2. Draw an elevation of the same parts of the… … 6 M 316 METAL-WORK
Metal-work
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
