Padding Machine for Dyeing Piece Goods withPyrogene Dyestuffs. a = Wood or Iron Troug-h, holding- 20—40 g-allons. b = Closed Steam Coil (iron or lead). c = Guide Rollers. d = Lower Squeezing Roller (to which driving- pulley is attached). e = Upper Squeezing Roller. / = Compound Lever for Regulating… … a = Tank for filling Dye Vessels. c = Guide Rollers in Dye-vats. c = Squeezing Rollers. g = Spirt Pipes. k = Shows method of drawing: oflf goods for dev achine for Pyroxene Dyestuffs. (Section.)
Dyes and dyeing
