Dynamo-electricity: its generation, application, transmission, storage and measurement (1884)
Prescott, George B. (George Bartlett), 1830-1894 · New York, D. Appleton · leaf 707
T. inder with flat parallel ends, having a steel shaft runningthrough its axis, and fixed to it bj means of radial armsor by blocks of wood driven into the cylinder at intervals. Thisshaft rests in bearings, and a pulley is arranged to drive it, Isurround this cylinder parallel to its axis with an… … Fig. 455. winding in the same direction, a second turn, and in this wayseveral coils in succession, and I join the ends of the wire thuswound to a galvanometer. Diametrically on each side of thecylinder I place magnets, each having their opposite poles turnedtoward the cylinder. The magnet on one…
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
