Dynamos and motors; a text book for colleges and technical schools (1911)
Franklin, William S. (William Suddards), 1863-1930, Esty, William, 1868-1928 · New York The Macmillan company · leaf 103
^ represents the harmonic current which the electromo-tive force produces in a circuit having resistance and inductance ;and the dotted curve in Fig. 74 represents the harmonic currentwhich the electromotive force produces in a circuit having resist- … Fig. 74. Circuit having resistance and contain ng a condenser. ance and containing a condenser. It is to be noted that the maxi-mum positive value of the current occurs after the maximum posi-tive value of the electromotive force in Fig. J}^, and before themaximum positive value of the…
Dynamos · Electric motors
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
