Figures 275 and 276 show the field member of a four-polesingle-phase series motor of the Westinghouse Electric andManufacturing Company. The field windings and the neutraliz- … Fig. 275. ing windings are both shown in position in Fig. 275, and in Fig.276 the field coils are removed so as to expose the neutralizingwindings to view. The neutralizing windings are placed in slotsin the laminated pole pieces, and the portions aaaa and bbbb. THE SINGLE-PHASE SERIES MOTOR. Z77…
