Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 232

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 232
show-ing the direction of load, the direction of sup-port, and the axis of rotation with angularquarter-curve bearings and angular thrust. 878. ACETYLENE BICYCLE LAMP.Gas is generated in the lower compartmentby admission of water in small quantitiesfrom the compartment B, through a needlevalve… … 879. ACETYLENE BICYCLE LAMP.—A charge of pulverized calcium carbide is placed inthe lower chamber. A charge of water of one-half the weight of the carbide is placed in thetank, J. The wick G carries water to the car-bide by capillary action and pressure from grav-ity. The gas is aerated in the…
