arallel are discussed in Art. 70 and the essential connections ofthree compound generators operating in parallel are shown inFig. 91. The equalizing bus bar is a connection which placesthe three series field windings in parallel with each other inde-pendently of the parallel connections of the… … F F \SLjisismJ Fig. 284.G^ and G^^ are two compound generators, J^^ and F^^ their shunt field windings,/?^ and A^ their shunt field rheostats, and C^ and C^^ their series field windings. •Sand .V^ are two triple-pole switches, A^ and A^^ are ammeterSj s^ and s^ areammeter shunts, and £ and £^^ are…
