Fig. 40. erator is shown in Fig. 40 ; the lower part of the figure is the finewire winding (shunt) and the upper part of the figure is the coarse … Fig. 41. wire winding (series), which, in this case, is made of copper stripbent edgewise. Figure 41 shows a brush holder of the General Electric Com-pany. The current is led from the carbon block (the brush) tothe metal part of the holder by the flexible cable of fine copper 58 DYNAMOS AND MOTORS.…
