Dynamos and motors; a text book for colleges and technical schools (1911)
Franklin, William S. (William Suddards), 1863-1930, Esty, William, 1868-1928 · New York The Macmillan company · leaf 71
Fig. 44 turns of heavy wire having a low resistance. In this case thefield winding is connected in series with the external receivingcircuit, the whole current delivered by the machine flows throughthe field winding, and from two to ten per cent, of the electro- … motive force of the machine is used to force the current throughthe field windincr. the remainder beine available for forcine cur- THE DYNAMO AND THE TRANSFORMER. 6i rent through the external receiving circuit. A direct-currentgenerator with its field windings arranged in this way is called ascries…
Dynamos · Electric motors
