fthe booster by means of the load current in such a way that,when the load is heavy the booster will assist the battery todischarge, and when the load is light the booster will assist the.generators to charge the battery. 207. The Differential Booster in its simplest form is connectedas shown in… … Fig. 194.—Differential booster svstem of batterv control. the m.m.f. of the series coils is equal and opposite to that of theshunt coils and the resultant magnetic field is zero, so that thebooster voltage is zero and the battery neither charges nordischarges. If the load on the generator…
