Easy steps in architecture and architectural drawing .. (1915)
Hodgson, Frederick Thomas, 1836- [from old catalog] · Chicago, Ill., Printed by F. J. Drake & co. · leaf 520
Fig. 123. him on this point, the following examples aresubmitted for him to study and work out. Thearch shown at Fig. 122 is simply a semicircularone, and the simple line of arch is drawn froma center as shown. When an arch of this formis used for brick or stone work as shown at Fig.123, a new set…
Architecture · Architectural drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
