Easy steps in architecture and architectural drawing .. (1915)
Hodgson, Frederick Thomas, 1836- [from old catalog] · Chicago, Ill., Printed by F. J. Drake & co. · leaf 529
V Fig. 127 Tudor arch. It is struck from three centers asshown. It is sometimes called an ellipticalGothic arch, and may be struck as follows: ARCHITECTURAL DRAWING SELF TAUGHT 133 Divide the span, ad, Fig. 128, into three equalparts by the points, ef. From a, with radius a,/,describe an arc, and…
Architecture · Architectural drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
