ARCHITECTURAL DRAWING SELF TAUGHT 163 Each item, too, has a constructive value^ asall are drawn from examples of actual work,and will, therefore, convey in some measure atrue knowledge of construction, without whichthe work of the mechanical draftsman has butlittle value. Straight Line. … Fig. 166. SOME ORNAMENTAL EXAMPLES We have now reached a stage where anattempt at ornamental geometrical drawing ispermissible, and though it is not my intentionto go deeply into this subject, a few examplesalong with brief descriptions will probably startsome of my readers on a course of…
